Product characteristics: Adopt advanced DSP digital control technology Overall efficiency up to 96% Adopt bidirectional DC design, charging current 1~12A can be freely set on the panel Power factor 0.9 (optional 1.0) Self-set output voltage 208/220/230/240Vac, frequency 50Hz or 60Hz The overall efficiency of ECO mode is more than 98%
Model Technical characteristics and parameters | BZR111B | BZR111L | BZR112B | BZR112L | BZR113B | BZR113L | |
Output capacity | 1000VA/900W | 2000VA/1800W | 3000VA/2700W | ||||
Input | Voltage range | 115~300VAC±5 | |||||
Frequency range | （45~55）±0.5Hz | ||||||
Bypass voltage | 80VAC×(1±5%)～285VAC×(1±5%) | ||||||
Battery input | Battery voltage | 24V | 36V | 48V | 72V | 72V | 96V |
Battery method | Internal | External | Internal | External | Internal | External | |
Fallback time (half/full) | Half load≥ 10 minutes, full load ≥5 minutes (standard) | ||||||
The maximum inrush current is input at power-on | < 150% of rated current | ||||||
Battery charging time | 5 hours charge to 90% (standard type) depends on external battery pack capacity (long-life type) | ||||||
Output | Voltage | 220Vac±1%（Inverter output） | |||||
Frequency | 50±5Hz（AC input is normal） 50Hz±1%（AC input is abnormal） | ||||||
Wave form | sinusoidTHD <3%（Liner load） sinusoidTHD <8%（Non-liner load） | ||||||
Power factor | 0.9 | ||||||
Overload capacity | The 130% load lasts for not less than 30s, and the recovery point is 90% load | ||||||
Output Current Crest | 3：1 | ||||||
Mains power, battery switching time | 0ms | ||||||
Tower | Communication and monitoring functions | RS232（Transferable485），Dry node, intelligent slot (can expand SNMP, SMS and other monitoring methods) | |||||
Weight（KG） | 8.5 | 5 | 17 | 9.9 | 22.5 | 10.5 | |
Dimension（W×D×H） | 355×145×225 | 425×190×320 | |||||
Rack | Weight（KG） | 10.8 | 7.5 | 19.5 | 10.5 | 24.5 | 12.5 |
Dimension（W×D×H） | 460×440×90 | ||||||
Installation method | Rack and wall mounting methods are compatible | ||||||
