Phase number：3ph—3ph Power capacity：150KVA/135KW Input rated voltage:380V/400V/415 VAC. power factor: ≥0.99 Frequency range:40~70Hz Rated output voltage:380V/400V/415VAC.
Model | BSM33150 |
Phase number | 3ph—3ph |
Power capacity | 150KVA/135KW |
Machine efficiency | ＞95% |
Input | |
Rated voltage | 380V/400V/415VAC |
voltage range | 208~478VAC |
frequency range | 40~70Hz |
power factor | ≥0.99 |
Input current harmonic | ≤3% （100% nar load） |
output | |
Rated output voltage | 380V/400V/415VAC |
voltage accuracy | ±1% |
Output frequency | Synchronization with input; when the power frequency exceeds the maximum (±10%) (setting (±1%, ±2%, ±4%, ±5%), the output frequency is 50 *(±0.2) Hz. |
Switching time | 0 ms |
power factor | 0.9 |
Overload capacity | Load ≤ 110%, 60 min, ≤125%, 10 min, ≤ 150% for 1 min, ≥ 150% for shutdown immediately |
Output Voltage Distortion | ≤2% linear load |
≤ 5% Nonlinear Load | |
Efficiency | Normal mode ≥95% |
Communication interface | RS232、RS485、2 Intelligent Slot (Smart Card Slot), Dry Contact |
Battery voltage | ±192V/±204V/±216V/±228V/ ±240V DC; (Sections 32, 34, 36, 38 and 40 are optional) |
Peak load ratio | 3：1 |
Battery mode efficiency | 95% |
Battery DC voltage | ±192V / ±240 V Adjustable |
Charging current | 10A-20A Adjustable |
Work environment | |
working temperature | 0-40℃ |
relative humidity | 0-95% (no condensation) |
Storage temperature | -25℃ ~ 55℃ |
Altitude | < 1500m |
physical characteristics | |
UPS Weight (kg) | 290kg |
Dimension WDH | 600 x 840x 1400 mm |
